GREENTECH DTHR 600 – Truck Mounted Drilling Rig
The GREENTECH DTHR 600 is a truck-mounted, multipurpose drilling rig designed for water well drilling up to 600 meters. Powered either by an Ashok Leyland 8x4 truck engine or a separate deck engine, it delivers powerful performance in DTH and Rotary drilling modes. Equipped with a 7½" x 10" mud pump, advanced hydraulic system, and heavy-duty mast, the rig ensures efficiency, reliability, and high productivity across all terrains.
Technical Specifications
| Category | Specification |
|---|---|
| Drilling Capacity | Hole Dia (DTH): 6.5" (Continuous), 9", 10", 12" (Overburden) Hole Dia (Rotary): 8" (Continuous), 12 ¼", 16" (Overburden) Depth: 600 meters |
| Mounting | Truck Mounted (Ashok Leyland 2825 8x4) |
| Prime Mover | Deck Engine or Truck Engine Power: 218 HP |
| Application | Water Well Drilling Rig |
| Formation Suitability | Soft Rock / Hard Rock / Unconsolidated / Alluvial |
| Mast | Hydraulic cylinder with pulley & wire rope Max Pull-up Force: 32,840 kg Max Pull-down Force: (as per design) Reeving Ratio: 1:3 Max Pull-up Speed: 35 m/min Max Pull-down Speed: 45 m/min |
| Rotary Head | Max Speed: 0–170 RPM Max Torque: 1300 kg.m |
| Hydraulic System | Max Working Pressure: 320 kg/cm² Pumps: Load Sensing |
| Hydraulic Oil Cooler | 120 gpm / 150 gpm |
| Break Out Wrench | Max Torque: 500 kg.m² Cylinder Bore: 80 mm / 100 mm Stroke: 300 mm / 350 mm |
| Levelling Jacks | Four Box-Type Hydraulic Levelling Jacks |
| Water Injection Pump | Triplex Reciprocating Pump powered by Hydraulic Motor |
| Rod Handling | Manual rod changer for single rods 1000 kg pull-up winch for drill rods & hammer tools |
| Mast Raising Cylinder | Bore: 125 mm Stroke: 800 mm Quantity: 2 Nos. |
| Air Compressor | 1200 CFM – 330 PSI or 1100 CFM – 300 PSI (As per customer request) |
| Air Line Lubricator | 18 liters |
| Mud Pump | Capacity: 7½" x 10" Stroke: 10" Flow: 2494 lpm Pressure: 20.74 kg/cm² |
| Optional Attachments | Shock Sub, Stem Lock, Hole Sweeper, Dust Collector, Digital Controls, Auto Drilling, Auto Rod Charger, GPS, Driller AC Cabin, Data Logging System, Welding Generator, Six Rod Carousel, Mud Pump |
